The use method of the electric torque wrench calibrator, the torque wrench calibrator must be operated correctly in order to get the best state, only the correct operation can make oneself get the most accurate results. Torque wrench calibrator is a special equipment for calibrating torque wrench and torque screwdriver. Our torque wrench calibrator is mainly used to calibrate various fixed-force torque wrenches, digital display torque wrenches, preset torque wrenches, dial-type torque wrenches, torque lifters, screwdrivers and various instruments and products related to tightening force.

　　扭矩扳手檢定儀使用方法

　　Use Method of Torque Wrench Verification Instrument1、在使用扭矩扳手檢定儀之前，先檢查儀器電量是否充足，若電量不足,請先充電（充電時也可使用）。

　　1. Before using the torque wrench calibrator, check whether the power of the instrument is sufficient. If the power is insufficient, please charge it first (it can also be used when charging).

　　2、將被檢物的四方測頭放入該檢定儀的承力四方孔內，同時使用得被檢物另一端的手柄在高度調節塊上方（若長度不夠時，可自由調節整套加載裝置）。

　　2. Put the quadrangular probe into the bearing quadrangular hole of the calibrator, and use the handle at the other end of the object above the height adjustment block (if the length is not enough, the whole loading device can be adjusted freely).

　　3、打開電源開關，顯示的扭矩值為零，如果不為零，則按清零鍵，將扭矩值清零。

　　3. Turn on the power switch and the displayed torque is zero. If it is not zero, press the reset button to reset the torque.

　　4、測試前，需設置好上下限值、很小存儲值、很小峰值保持值、自動峰值時間、自動關機時間、重力加速度等.

　　4. Before testing, it is necessary to set up upper and lower limits, very small storage values, very small peak holding values, automatic peak time, automatic shutdown time, gravity acceleration and so on.

　?、?、上限值設定：用戶設定上限值，根據需要自由設定，達到上限值即自動聲光提示，上限值不高于滿量程。

　　(1) Setting the upper limit: Users set the upper limit, set it freely according to need, and reach the upper limit, that is, automatic acousto-optic prompt. The upper limit is not higher than the full range.

　?、?、下限值設定：用戶設定下限值，根據需要自由設定，達到下限值即自動燈光提示，下限值不得高于設定的上限值。


　　(2) Lower Limit Setting: Users set the lower limit, set it freely according to need, and reach the lower limit, i.e. automatic light prompt. The lower limit should not be higher than the set upper limit.

　?、?、很小存儲值設定：用戶根據存儲需要設定很小存儲值，小于該值的數據將不被儲存。

　　(3) Very small storage value setting: users set very small storage value according to storage needs, and data less than that value will not be stored.

　?、?、很小峰值保持值設定：用戶根據峰值，自動峰值測量需要自由設定，小于該值的數據不被峰值保存。

　　(4) Very small peak holding value setting: According to the peak value, users need to set the automatic peak measurement freely, and the data less than that value is not saved by the peak value.

　?、?、自動峰值時間設定：用戶根據自動峰值測量狀態下峰值需要保持的時間從1秒～99秒自由設定。

　　_. Automatic peak time setting: The user can set the peak time from 1 second to 99 seconds freely according to the peak value of automatic peak measurement.

　?、?、自動關機時間設定：無操作狀態下，自動關機時間從0分鐘～9分鐘可自由設定（當設置為0分鐘則表示為解除自動關機）。

　　_. Automatic shutdown time setting: In the state of no operation, the automatic shutdown time can be set freely from 0 minutes to 9 minutes (when set to 0 minutes, it means to release the automatic shutdown).

　?、摺⒅亓铀俣仍O定：用戶可根據本地區的位置設定重力加速度值，本機默認9.794。

　　_. Gravity acceleration settings: Users can set the gravity acceleration value according to the location of the area, the default of this machine is 9.794.

　?、唷⒒謴统跏荚O置：用戶操作不當或多次更改數據出現混亂,可以通過此項設置來把1～7的數據恢復到出廠狀態。

　　_. Restore the initial settings: Users can restore 1-7 data to factory status through improper operation or confusion of changing data several times.
